Description

GASGAS MC 85 19/16 2027

Technical details

Engine

• Primary drive: 20:64
• Transmission: 6-speed
• Cooling: Liquid cooled
• Secondary gear ratio: 13:49
• Starter: Kickstarter
• Stroke: 48.95 mm
• Bore: 47 mm
• Clutch: Wet, multi-disc clutch, Formula hydraulics
• Displacement: 84.9 cm³
• EMS: Keihin PWK 28
• Design: 1-cylinder, 2-stroke engine

Chassis

• Weight: (without fuel) 69 kg
• Tank capacity: (approx.) 5.4 l
• Wheelbase: 1282 mm
• Front brake disc diameter: 240 mm
• Rear brake disc diameter: 220 mm
• Front brake: Disc brake
• Rear brake: Disc brake
• Chain: 428, Non-sealed
• Frame design: Central-tube frame with double-cradle
• Front suspension: XACT 43 WP Upside-Down fork, Ø 43 mm
• Ground clearance: 333 mm
• Handlebar: Aluminium, tapered Ø 28/22 mm
• Rear suspension: XACT WP PDS mono shock
• Seat height: 871 mm
• Silencer: Aluminium
• Steering head angle: 63.5 °
• Rear subframe design: Aluminium / Polyamide Glass Fiber
• Suspension travel (front): 278 mm
• Suspension travel (rear): 289 mm
• Tyre dimensions (front/rear): 70/100; 90/100
• Wheels: 1.6 x 19"; 1.85 x 16"
• Wheelbase: 1282 ± 10 mm
